Elix 20,35,70,100 Water Purification Systems
Type 2 analytical-grade water
Produce Up to 4000 L/day of Pure Water
Elix systems are designed to produce up to 4000 L/day of Type 2 analytical-grade water from potable tap feedwater to meet or exceed the relevant standards defined by CLSI, ISO® 3696 / BS 3997 and the European and US Pharmacopoeia.
One Complete Purification and Control Unit
Elix systems can be integrated into a centralized system, providing total control of all parameters within the system itself as well as within the external pure water distribution loop.
Applications
Elix product water is suitable for the following applications:
● Microbiological media preparation
● Buffer preparation
● Hydroponics
● Manufacturing chemical and biochemical reagents
● Pharmaceutical use of purified water
● Feed for laboratory equipment
● Feed to Milli-Q and Super-Q ultrapure water systems
Features
● Total control of all functions, operating parameters and standard accessory components within the Elix system itself and within the external pure water distribution loop Patented Elix electrodeionization module continuously regenerates ion-exchange resins
● Built-in resistivity and TOC (Total Organic Carbon) monitoring to ensure water quality
● No additional softeners are required for most feedwater conditions
● Easy-to-replace pretreatment packs, tailored to the feedwater source
● Built-in UV lamp for bacteria-sensitive applications
● Built-in UV lamp for bacteria-sensitive applications
● Systems contain integrated control functions for distribution loop components (pump, UV lamp, ASM, TOC and resistivity meters)
規格說明 ：
Type 2 analytical-grade water
Produce Up to 4000 L/day of Pure Water
Elix systems are designed to produce up to 4000 L/day of Type 2 analytical-grade water from potable tap feedwater to meet or exceed the relevant standards defined by CLSI, ISO® 3696 / BS 3997 and the European and US Pharmacopoeia.
One Complete Purification and Control Unit
Elix systems can be integrated into a centralized system, providing total control of all parameters within the system itself as well as within the external pure water distribution loop.
Applications
Elix product water is suitable for the following applications:
● Microbiological media preparation
● Buffer preparation
● Hydroponics
● Manufacturing chemical and biochemical reagents
● Pharmaceutical use of purified water
● Feed for laboratory equipment
● Feed to Milli-Q and Super-Q ultrapure water systems
Features
● Total control of all functions, operating parameters and standard accessory components within the Elix system itself and within the external pure water distribution loop Patented Elix electrodeionization module continuously regenerates ion-exchange resins
● Built-in resistivity and TOC (Total Organic Carbon) monitoring to ensure water quality
● No additional softeners are required for most feedwater conditions
● Easy-to-replace pretreatment packs, tailored to the feedwater source
● Built-in UV lamp for bacteria-sensitive applications
● Built-in UV lamp for bacteria-sensitive applications
● Systems contain integrated control functions for distribution loop components (pump, UV lamp, ASM, TOC and resistivity meters)
檔案下載 ：
| Elix 20 | Elix 35 | Elix 70 | Elix 100 | |
|
Flow Rate, L/h (± 15% at 7 ° C< T <30 °C) |
20 | 35 | 70 | 100 |
|
Resistivity, MΩ·cm (Compensated to 25 °C)* |
> 5 Pure Water: > 5 |
> 5 Pure Water: > 5 |
> 5 Pure Water: > 5 |
> 5 Pure Water: > 5 |
|
Conductivity, µS/cm (compensated to 25 °C)* |
< 0.2 | < 0.2 | < 0.2 | < 0.2 |
| TOC, ppb | ||||
| Bacteria Count, cfu/mL | < 10 | < 10 | < 10 | < 10 |
| Silicate Removal, % | >99.9 | >99.9 | >99.9 | >99.9 |
| Water Recovery, % | Up to 30 | Up to 40 | Up to 50 | Up to 50 |
| Dimensions | ||||
| Height, cm (in.) | 73.4 (28.9) | 73.4 (28.9) | 73.4 (28.9) | 73.4 (28.9) |
| Width, cm (in.) | 66.2 (26.1) | 66.2 (26.1) | 66.2 (26.1) | 66.2 (26.1) |
| Depth, cm (in.) | 44.1 (17.4) | 44.1 (17.4) | 44.1 (17.4) | 44.1 (17.4) |
| Operating Weight, kg (lb) | 45 (99) | 48 (106) | 56 (123) | 62 (137) |
| *[CO2] <30 ppm in feedwater: typically 10– 15 MΩ·cm | ||||
| Please contact your local Millipore representative for more detailed information and to determine the best configuration to meet your needs. | ||||
